Tech Specs
Measurement Specifications
Measurement Principle: Light Scattering
Primary Measurement Data: PM2.5, PM1.0
Secondary Measurement Data:PM4.0, PM10, Temperature, Humidity, Atmospheric Pressure
PM Measurement Units: μg/m³ and counts/m³
PM Measurement Range: 0 – 1000 μg/m³ and 0 – 55,000 counts/m³ (before ML correction)
Measurement Resolution: 0.1 μg/m³ and 1 count/m³
Measurement Interval: 5 seconds
Automatic Humidity Control: Built-in automatic tiny aerosol conditioner
Operating Temperature: -20°C – 70°C
Operating Relative Humidity: 0 – 100% RH
Buillt-in GPS: real-time location tracking and location-based services
Power & Physical Specifications
Power Supply: AC 100 – 240V
Power Consumption: 2.1W (typical at 25°C, 60% RH), max 4.7W
Dimensions (W × D × H, cm):
– Main Unit: 13.8 × 8 × 17
– With Enclosure: 22.0 × 16.0 × 22.6
Weight:
– Main Unit: 930g
– with band bracket & enclosure: 4.19kg
– with short stand & enclosure: 4.335kg
– with long stand & enclosure: 8.92kg
Warranty: 1 year
Serial Communication & Data Management
Serial Interface: RS232 serial communication for local data logging and diagnostics
Device Management Software:
– GG Tool (GUI) for Windows 10 or higher and macOS (14.6 or higher)
– ggserial (CLI) for Windows, macOS, and Linux
Data Logging:
– Local Logging Interval: Selectable (1, 5, 10, 30, or 60 minutes)
– At 1-minute logging, up to 28 years of storage with 1GB memory
Server Logging: 1-minute or 10-minute intervals, stored in server database
– Data access and download available at (https://airnow.kr/ggtam)
Embedded Multitask Operating System:TAM OS
Smart Connectivity
Mobile App Support: Air Alarm G (Android, iOS, and macOS)
IoT LTE-M1 Modem: supports AMT5920SK (not included)
Wi-Fi: Wi-Fi 802.11b/g/n 2.4GHz
Wi-Fi Security: WEP / WPA-PSK / WPA2-PSK
Wireless Data Transmission Interval: Selectable between 1 minute and 10 minutes
Wireless Data Integrity: Anti-tampering data transmission technology is applied
